Model | FK500F | FK700F | FK980F | FK1200F |
Lanes nûmer | 2-4 banen | 3-6 banen | 4-8 leane | 5-10 baan |
Kapasiteit | 25--40 cut / lan Max.25-40cycle / min / lane | |||
Bag grutte | L: 45-160 mm W: 50-125 mm | L: 45-160 mm W: 50-125 mm | L: 45-160 mm W: 50-125 mm | L: 45-160 mm W: 50-125 mm |
Filmbreedte en dikte | Max.500mm,0.07--0.1mm | Max.700mm,0.07--0.1mm | Max.980mm,0.07--0.1mm | Max.1200mm,0.07--0.1mm |
Mjitmetoade | 1.koarte auger; 2.koarte auger mei beker | |||
Sealing type | 4 kanten sealing | 4 kanten sealing | 4 kanten sealingg | 4 kanten sealing |
Snijtype | 1.Straight cutting;2.Zig-zag-snijen; 3 Trochrinnend snijden | |||
Streamtafier | 50HZ/AC220V/380V/2.8kw | 50HZ/AC220V/380V/4.1kw | 50HZ/AC220V/380V/5.5kw | 50HZ/AC220V/380V/7.5kw |
Loftferbrûk | 0,8 MPA 0,8m3/min | 0,8 MPA 0,8m3/min | 0,8 MPA 0,8m3/min | 0,8 MPA 0,8m3/min |
Diminsje | 950 * 1470 * 1750 mm | 1153 * 1654 * 1750 mm | 1415 * 1686 * 2130 mm | 2220 * 2210 * 2600 mm |
Gewicht | 400kg | 550 kg | 650kg | 900kg |
